QE型通用桥式起重机

QE型通用桥式起重机依据GB/T14405-2011标准所设计、制造.该型号起重机是在QD型起重机基础上设有两台起重小车，其可以单独工作，也可以联台动作，适用于工矿企业车间及铁路、港口码头等货场吊运长件物品。
本产品起重量般为(2.5+2.5)t、(5+5)t、(10+10)t、(15+15)t、(20+20)t，跨度为7.5～31.5m，工作级别一般为A5～A6级，其主要特点基本与QD型产品相同．

    Different from QD crane QE overhead crane has two trolleys that can be drived respectively or together ,For that reason it can hoisl and convey long items in railway stations mines and steel plate worksnops,etc.

Performance data
Range of lifting load(2.5+2 .5)t、(5+5)t、(10+10)t、(15+15)t、(20+20)t、

Range of span 7.5～31.5 m

Allowed crane classification group A5～A6

The crane’s main features refer to those of QD model.
